Original Prusa XL+ 3D printer

PrusaAvailability on request

Price

€2,658.47

Price excluding VAT. The VAT of the delivery country is added.

Business price (excl. VAT)

Selected option: 1 · No

Number of toolheads/extruders

Enclosure

Illustrative model 3D model generated from product photos, at the dimensions in the datasheet. Details may differ from the product. Licenses and attributions

Product details

Package weight34 kg

Product dimensions (manufacturer)70 × 72 × 90 cm

Package dimensions90 x 70 x 72 cm

CategoriesFDM, 3D printers

Description

The Original Prusa XL+ is a CoreXY 3D printer with an active toolchanger and a huge 360 × 360 × 360 mm build volume (46.7 L). It can print up to 5 materials in a single job with no cross-contamination and minimal purge waste. Each toolhead has its own extruder, hotend, nozzle and filament, and parked toolheads stay preheated for instant changes. You can start with 1 toolhead and expand to 2 or 5 at any time, because the frame is already prepared.

A unique segmented bed with 16 individually controlled zones heats only the active area. This eliminates warping and saves energy.

Key features

Active toolchanger: up to 5 toolheads, one job, up to 5 materials
Huge volume: 360 × 360 × 360 mm (46.7 L)
16-zone segmented bed: heats only the active area and prevents warping
Expandable: start with 1 toolhead and expand to 2 or 5 later
Mixed materials and nozzles: rigid, flexible and soluble support materials, with nozzles from 0.25 to 0.8 mm
Optional enclosure: up to 50 °C, or 60 °C with an external heater
Open filament policy: any 1.75 mm brand, no chips or subscriptions

Choose your configuration

1 toolhead: large parts in a single material
2 toolheads: soluble supports or two materials, the engineering sweet spot
5 toolheads: multi-material and multicolor production
With an enclosure: a stable environment for engineering materials without warping
Without an enclosure: open frame

Typical uses

Multi-material and multicolor production parts
Engineering parts with soluble supports
Large parts in a single material with the 1 toolhead version
Parts that combine rigid and flexible materials

Technical specifications

Specification	Value
Technology	CoreXY, active toolchanger
Build volume	360 × 360 × 360 mm (46.7 L)
Toolheads	Up to 5 independent toolheads, automatic swapping
Toolhead calibration	Fully automatic (dedicated electronic sensor)
First layer calibration	Fully automatic (LoadCell)
Extruder	Nextruder, direct drive
Max nozzle temperature	290 °C
Heated bed	Segmented, 16 individually controlled zones, up to 120 °C
Enclosure (optional)	Up to 50 °C with the enclosure, up to 60 °C with an external heater
Nozzles	0.4 mm high-flow (default), 0.25 / 0.6 / 0.8 mm, hardened, CHT
Filament diameter	1.75 mm
Materials	PLA, PETG, ASA, ABS, PC, PA, TPU, PVA, HIPS, PP, CPE, PVB, carbon fiber composites
Motion system	CoreXY, GT 1.5 mm belts, Input Shaper, Phase Stepping
Print surface	Double-sided satin sheet, removable
Connectivity	Ethernet, optional Wi-Fi, fully offline operation
Machine dimensions	Approx. 70 × 90 × 72 cm
Weight	Approx. 30 to 34 kg (depending on the number of toolheads)
Firmware	Open-source
Made in	EU and USA

Share:Facebook LinkedIn WhatsApp

Frequently asked questions

How many toolheads can the XL+ have?

You can choose 1, 2 or 5 toolheads. You can start with 1 and expand to 2 or 5 at any time, because the frame is already prepared.

Do I need to buy the enclosed version?

No, it is available with or without an enclosure. The enclosure provides a stable environment of up to 50 °C, or 60 °C with an external heater, for engineering materials without warping. The open frame version has no enclosure.

Can I use filament from any manufacturer?

Yes. The printer uses open 1.75 mm filament from any brand, with no chips or subscriptions.

Which materials does it support?

The listed materials are PLA, PETG, ASA, ABS, PC, PA, TPU, PVA, HIPS, PP, CPE, PVB and carbon fiber composites. The maximum nozzle temperature is 290 °C and the bed reaches 120 °C.

Does it need an internet connection?

No. It connects through Ethernet or optional Wi-Fi and can work fully offline.
