MINGDA MD-600D 3D printer

MINGDAOn order

Price

Request a quote

Illustrative model 3D model generated from product photos, at the dimensions in the datasheet. Details may differ from the product. Licenses and attributions

Product details

Weight335 kg

Product dimensions (manufacturer)132.5 × 96.5 × 126.5 cm

Package dimensions97 x 133 x 127 cm

CategoriesFDM, 3D printers

Description

The MINGDA MD-600D is a large-volume industrial FDM 3D printer with a closed enclosure and a dual extruder for printing in several materials or with support material. A 350 °C nozzle handles engineering filaments, while a 10 mm aluminum build plate with magnet and PEI surface, fast automatic leveling and remote control with multi-machine management keep daily operation simple. It is delivered assembled and calibrated, marked "Ready to Print".

Key features

Large build volume of 600 × 600 × 600 mm
Dual extruder for multi-material printing or printing with supports
Nozzle up to 350 °C for engineering filaments such as CF/GF composites, PPS and nylon
Speed up to 300 mm/s with a flow rate of 40 mm³/s
Delivered calibrated and assembled
10 mm aluminum build plate with magnet and PEI, plus automatic leveling
10 inch color touchscreen with WiFi, remote control, multi-machine management and power loss recovery

Typical uses

Large functional parts and fixtures that do not fit on desktop machines
Multi-material prints and prints with support material using the dual extruder
Parts in engineering filaments such as CF/GF composites, PPS and nylon
Workshops and labs that want to manage several machines remotely

Technical specifications

Specification	Value
Technology	FDM
Build volume	600 × 600 × 600 mm
Extruder	Dual
Layer height	0.3 to 0.36 mm
Filament diameter	1.75 mm
Nozzle diameter	0.6 mm (optional 0.4 and 0.8 mm)
Max nozzle temperature	350 °C
Max bed temperature	110 °C
Enclosure temperature	45 °C
Max print speed	300 mm/s
Max flow rate	40 mm³/s
Resolution	XY 20 µm, Z 10 µm
Max power	2400 W
Input voltage	220 V, 50/60 Hz
Connectivity	WiFi, Ethernet, USB
Screen	10 inch color touchscreen
Software	MINGDA Slicer
Build plate	10 mm aluminum with magnet and PEI
Leveling	Automatic, fast
Certification	CE
Machine dimensions	1325 × 965 × 1265 mm
Weight (packaged)	335 kg
Compatible materials	PLA, PETG, PETG-CF, PET-CF/GF, ABS-CF/GF, PA12-CF, HtPA-CF/GF, PPS, PPS-CF/GF, S-Multi, S-HtPA

Share:Facebook LinkedIn WhatsApp

Frequently asked questions

What is the build volume?

The build volume is 600 × 600 × 600 mm.

Which materials can it print?

The nozzle reaches 350 °C. Compatible materials listed by the manufacturer are PLA, PETG, PETG-CF, PET-CF/GF, ABS-CF/GF, PA12-CF, HtPA-CF/GF, PPS, PPS-CF/GF, S-Multi, S-HtPA.

Does it arrive ready to use?

Yes. It is delivered assembled and calibrated, marked "Ready to Print".

How is it connected and controlled?

It has WiFi, Ethernet and USB, a 10 inch color touchscreen and remote control with multi-machine management. Slicing is done with MINGDA Slicer.

What power supply does it need?

It runs on 220 V, 50/60 Hz with a maximum power of 2400 W.
